| Forklift Battery Type | Lead–Acid Battery | Terrain Adaptability | Indoor Flooring, Outdoor Pavement, Rough Terrain |
| Load centre distance | 200mm(7.87in) | Mast Type | Two-Stage Mast, Three-Stage Mas, Single-Stage Mast |
| Forklift Turning radius | 1950 mm(76.77in) | Fork Width | 320mm(12.60in), 700mm(27.56in) |
| Fork Length | 1150 mm(45.28in) | Operating Mode | Manual Operation/Seated Operation |
| Drive Type | ED/RWD/AWD | Forklift Tyre | Non-Marking Tire |
| Travel speed ( laden) | 5 km/h(3.11mph), 4 km/h(2.49mph) | Grade ability （laden) | 0.15 |
| Grade ability（unladen) | 0.05, 0.06, 0.08, 0.15, 0.35 | Forklift Wheelbase | 1700 mm(66.93in), 1487mm |
| Mast Tilt Angle (Forward Tilt-Rear Tilt) | 6-12° | Side Shifter | Electric Side Shifter/Seated Operation |
| Fork Specifications( L*W*H) | 1150*190*60mm(45.28*7.48*2.36in) | Condition | New |
| Battery voltage (V/AH) | 48v/1600w | Fork height,lowered | 1560 mm-2505 mm(61.42in-98.62in) |
| Self-weight | 610kg(1344.82lb) | Fork width inside | 320mm |
| fork width | 710mm | Forklift height above the ground | 160mm |
| logo | customize | color | Customer Demanded Red |
| Loading weight | 1.5ton | Braking method | electronic brake |
| Vehicle length | 2320 mm/1930 mm (pedal deployed/retracted) | The lifting height can be customized | optional |
| Shelf lifting height 2m | static height 1560mm |
